● Access Point mode● LTE FDD/TDD Cat 4 ● AC1200 Wi-Fi● 1× 10/100 Mbps WAN/LAN● Nano SIM Slot● 24 V Passive PoE● 2× Internal WiFi Antennas + 2× Detachable 4G Antennas● VPN & DDNS ● IP65 WaterProof
ModelLT500-OutdoorLTE Module Model EU VersionEC200A LTE-FDD: B1/B3/B5/B7/B8/B20/B28 LTE-TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM/EDGE: B3/B8LTE Module Model US VersionEC25-AFXD LTE-FDD: B2/B4/B5/B12/B13/B14/B66/B71 WCDMA: B2/B4/B5Flash128 Mbit (16 MB) SPI FlashDDR1 Gbit (128 MB) DDRInterface1× 10/100 Mbps WAN/LAN RJ45 Port (24V/0.5A passive PoE, 4/5+,7/8-)1× Reset Button1× Nano SIM SlotLEDSystem/Internet/Ethernet/2.4G WiFi/5GHz WiFi/Signal StrengthAntenna2× Internal Wi-Fi Antennas2× External Detachable 4G AntennasWireless FeaturesWireless StandardsIEEE 802.11 ac/a/n/b/g Frequency2.4 GHz, 5 GHzSignal Rate867 Mbps (5 GHz), 300 Mbps (2.4 GHz) Compatible with 802.11ac/a/b/g/n Wi-Fi standardsTransmit PowerCE: <20dBmFCC:<30dBmWireless ModesEnable/Disable Wireless Radio, WMMWireless SecurityWPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSKMesh CompatibilityWorks with other Cudy Mesh products (as the main Mesh node)Software FeaturesWAN Type4G/Dynamic IP/Static IP/PPPoEDHCPServer, DHCP Client List, Address ReservationDynamic DNSCompatible with 15 more DDNS providersNATPort Forwarding, Port Triggering, UPnP, DMZVPN Sever & ClientPPTP/L2TP/OpenVPN/WireGuard/IPSec/ZerotierCWMP ProtocolTR069 / TR098 / TR111 / TR181ACS Server CompatibilityGenieACS, OpenACSManagementAccess Control, Local Management, Remote Management, Wake on LANTTLExtend/Spoof/CustomDNSCloudflare/Google/Quad9/CustomInternet ProtocolsIPv4 / IPv6 IPv6RelayDynamic(SLAAC/DHCPv6)Static (Fixed IP)PassthroughMAP-E (Dual-stack)DS-Lite (Dual-stack)SMSSend/Receive4G Band LockSupportOthersIngrees Protection RatingIP65 (Router only when installed vertically, the PoE Adapter is not waterpoof)Working Temperatures-20 ~ 60 °C (-4°F ~ 140°F) Extend -40 ~ 65°C (-40°F ~ 149°F) (Booted up in advance. Performance may drop slightly.)DimensionsRouter Body: 240×100×53.7 mm (9.5×3.9×2.1 inches) Antennas: 197.5×21.6×15.5 mm (7.8×0.9×0.6 inches) Height of Router with Antennas installed: 438 mm (17.2 inches)Package Content2× detachable 4G antennas24V/0.5A passive PoE adapterPole Installation AccessoryEthernet CableQuick Installation GuideSystem RequirementsWindows, MAC OS, NetWare, UNIX, or Linux Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other web browser If you are using 4G as your internet access, you will need a nano SIM card with an active data subscription, If you are using WAN as your internet access, you will need a fiber/cable/DSL modem or any other wired internet source.
